Standard samples, tubes, etc.
Share
Share
Add Bookmark
Last update: 5 June 2024
Standard sample
Name | P/N | Qty | Remarks | Applicable models |
---|---|---|---|---|
Standard sample for autotuning |
225-34260-01
|
400mL | Nal (sodium iodide) |
9030 |
Standard sample for autotuning |
225-14124-01
|
200mL | PEG (polyethylene glycol), raffinose |
8080 |
Standard sample for autotuning |
225-14122-01
|
200mL | PEG (polyethylene glycol), PPG (polypropylene glycol), raffinose |
8060 8050 8030 8040 |
Standard sample for autotuning |
225-14985-01
|
200mL | PEG (polyethylene glycol), PPG (polypropylene glycol), raffinose |
2020 |
Standard sample for autotuning |
225-06613-06
|
200mL | PEG (polyethylene glycol), raffinose |
2010 |
Drain tube, nebulizer gas tube
Name | P/N | Qty | Remarks | Applicable models |
---|---|---|---|---|
Silicone rubber tube for waste liquid |
016-31350-19
|
1m | For waste liquid from the waste tray |
8060 8050 8030 8040 2020 2010 |
PVC tube for waste liquid |
016-31414
|
1m | For waste liquid from the spray section |
9030 8060 8050 8030 8040 2020 2010 |
Rotary pump oil
Name | P/N | Qty | Remarks | Applicable models |
---|---|---|---|---|
Rotary pump oil LV0700 |
225-27850-02
|
1L | 2 L per use |
9030 8060 |
Rotary pump oil Ultragrade#19 |
017-30163-02
|
4L | 1.5 L per use |
except 8080 except 8060 |
Rotary pump oil GS495 |
017-30168-01
|
1L |
8080 |
Sample delivery unit (for LCMS-8080)
Name | P/N | Qty | Remarks | Applicable models |
---|---|---|---|---|
Syringe for autotuning |
225-25043-41
|
5mL | Inner diameter: 10.30 mm |
LCMS-8080 |
PTFE tube |
228-18495-01
|
1m | Cut the tube into 20 to 30 mm length pieces before use. |
LCMS-8080 |
PEEK nut |
228-18565-84
|
5 |
LCMS-8080 |
|
PEEK coupling |
228-25014
|
1 |
LCMS-8080 |
|
Tee joint |
225-25031-10
|
1 |
LCMS-8080 |
|
PEEK tube |
228-33833-91
|
3m | Inner diameter: 0.13 mm |
LCMS-8080 |
Straight joint |
225-25031-07
|
1 |
LCMS-8080 |
|
Tube cutter |
225-25031-08
|
1 |
LCMS-8080 |
|
Syringe for infusion analysis |
225-25031-02
|
1mL | Inner diameter: 4.61 mm |
LCMS-8080 |
Standard sample introduction unit (for LCMS-2010)
Name | P/N | Appearance | Qty | Remarks | Applicable models |
---|---|---|---|---|---|
Plunger assembly |
228-25237-17
|
1 | 5mL |
LCMS-2010 |
|
Reflex fitting set |
228-45407-92
|
Set of 5 | Used for pipe connection from the 6-port valve to the ESI/APCI probe |
LCMS-2010 |
|
Microsyringe1005C |
228-25237-07
|
1 |
LCMS-2010 |
